On this page, you will find high-resolution pictures of silicon dies. These pictures are typically taken of transistors and microchips.
Currently, I use a “Radical 2000x” metallurgical microscope with a Sony A6000 mirrorless camera. The pictures of transistors are usually “one-shot” pictures and the pictures of microchips are stitched panorama pictures. Sometimes I employ focus stacking too which I perform in Photoshop. The panorama stitching is done in Hugin, but I also use the Microsoft Image Composite Editor.
2N2907A
TDA1060B
2N5416
MC14536BCL
2N3439
2N2905
SCM10093L
LM248J
SFC 2301
MM56H80A
